- Camera
- Image Sensor3K CMOS
- Max. Resolution2960 (H) × 1665 (V)
- Min. Illumination0.02 Lux @ (F2.2, AGC ON), 0 Lux with IR
- Shutter TimePAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s
- Day & NightICR
- Angle AdjustmentPan: 0 to 360°, Tilt: 0 to 90°, Rotate: 0 to 360°
- Signal SystemPAL/NTSC
- Lens
- Lens Type2.8 mm, 3.6 mm fixed focal lens
- Focal Length & FOV
2.8 mm, horizontal FOV: 101°, vertical FOV: 64°, diagonal FOV: 125°
3.6 mm, horizontal FOV: 80°, vertical FOV: 51°, diagonal FOV: 98°
- Lens MountM12
- Illuminator
- Supplement Light Range
IR : Up to 20 m
White Light : Up to 20 m
- Supplement Light TypeSmart,IR,White Light
- Image
- Image Parameters SwitchSTD/HIGH-SAT/HIGHLIGHT
- Image SettingsBrightness, Sharpness, Smart IR
- Frame Rate
TVI: 3K @20 fps, 4 MP @25 fps/30 fps, 1080p @25 fps/30 fps
AHD: 5 MP @20 fps, 4 MP @25 fps/30 fps
CVI: 4 MP @25 fps/30 fps
CVBS: PAL/NTSC
- Day/Night ModeAuto/Color
- Wide Dynamic Range (WDR)Digital WDR
- Image EnhancementDWDR/BLC/HLC/HLS/Global
- White BalanceAuto/Manual
- AGCYes
- Interface
- Video OutputSwitchable TVI/AHD/CVI/CVBS
- General
- MaterialPlastic
- DimensionØ70 mm × 138.8 mm (Ø2.76" x 5.46")
- Max. 150 g (0.33 lb.)
- Operating Condition-40 °C to 60 °C (-40 °F to 140 °F). Humidity: 90% or less (non-condensation)
- CommunicationHIKVISION-C
- LanguageEnglish
- Power Supply
12 VDC ± 25%, Max. 4.4 W
*You are recommended to use one power adapter to supply the power for one camera.
- Approval
- ProtectionIP67
