Specifications
- Product codeRB1100x4
- Architecture
- ARM 32bit
- CPUAL21400
- CPU core count4
- CPU nominal frequency1.4 GHz
- CPU Threads count4
- Switch chip modelRTL8367
- Dimensions443 x 148 x 44 mm
- RouterOS license6
- Operating SystemRouterOS
- Size of RAM1 GB
- Storage size128 MB
- Storage typeNAND
- MTBFApproximately 200'000 hours at 25C
- Tested ambient temperature-40°C to 70°C
Powering
- Number of AC inputs2
- AC input range100-240
- Number of DC inputs2 (PoE-IN, 2-pin terminal)
- 2-pin terminal input Voltage-48, 12-57 V
- Max power consumption20 W
- PoE in802.3af/at
- Cooling typePassive
- PoE in input Voltage20-57 V
Ethernet
- 10/100/1000 Ethernet ports13
Peripherals
- Memory card typemicroSD
- Memory Cards1
- Serial console portRS232
Other
- Current MonitorYes
- PCB temperature monitorYes
- Voltage MonitorYes
- Mode buttonYes
- BeeperYes
Certification & Approvals
- CertificationCE, EAC, ROHS
- IPIP20
